Product advantages

• Probe specification :2.5MHz 3D mechanical sector scanning, sector scanning angle 120°



• Volume measurement range: 0 ml ~ 999 ml



• Volume measurement accuracy: ± 7.5%



• The volume measurement results are displayed in milliliters (ml).



• Scanning depth: ≥160 mm



• Qr code information of patients will be displayed after scanning



• There is a scan button on the screen, more convenient.



• There are arrows on the screen to guide the probe in the direction of movement.



• Store 1000 cases with store and print fuction



• Synchronize patient information to the host computer



• Interface multi-color display

Application Technology

• The device uses a 3D mechanical sector scanning probe to perform ultrasound detection of the bladder.



• The ultrasound imaging principle is used to measure the bladder volume through the abdominal body surface.



• The use of the product is not affected by bladder occupying lesions and can effectively identify the bladder wall.



Function display

• Probe specification: 2.5MHz 3D mechanical sector scanning, sector scanning angle 120°



• Volume measurement range: 0 ml ~ 999 ml



• Volume measurement accuracy: ± 7.5%



• The volume measurement results are displayed in milliliters (ml).



• Scanning depth: ≥160 mm



• Store 1000 cases with store and print fuction



• Synchronize patient information to the host computer



• Interface multi-color display

Applicable scenario

• Non-invasive and immediate detection of bladder volume, no need for professional ultrasound doctors, suitable for use in various departments.



• It can be used as a daily care device for the ward to reduce the urinary tract infection rate associated with the catheter (CAUTI),



• In the pelvic floor radiotherapy, monitor the bladder capacity to ensure accurate radiotherapy at the pelvic floor



• Evaluation of bladder function before and after gynecological pelvic floor surgery



• Evaluation of various urinary diseases, urinary management, bladder function monitoring



• Rehabilitation nursing of patients with neurogenic bladder, spinal cord injury and stroke patients, to help assess the recovery of bladder function.



• Before the implementation of intermittent catheterization, the measurement of bladder capacity and bladder pressure to set the catheterization time is conducive to the recovery and reconstruction of bladder function.



• Diagnose different types of urinary incontinence and dysuria, and determine the diagnosis and treatment plan.
